Products
Efficient liquid cooling system
Large capacity reliable power battery cell
Enhanced durability and environmental resistance
Intelligent monitoring and security features
Model
YY645K
Nominal voltage
576V
Nominal capacity
1120AH（280AH*4P）
Support in parallel
Max.16 clusters（280AH*16P）
Output port
Play and plug connector
Charger port
Dual gun DC fast charge
Size(mm)
4300*1480*1388MM
Weight
6100KG
Charging mode
DC charging pile-CC/CV
Charging current
560A(standard)
Max. Charge current(A)
Max.1120A@25°
Charging cut-off voltage
657V
Discharge current
560A
Max. Discharge current(A)
Max.1120A@25°
Discharge cut-off voltage
450V
Charging Temp Range(°C)
0~+55℃
Disharging Temp Range(°C)
-20~+65℃
Cooling method
Liquid cooling
